Accurate leakage current measurement Residual Current Monitoring Sensor

Features:

Single Supply +5 V

High and low level output

Self-test function

Mounted on PCB board

Applications:

Ground fault detection

Electric vehicle charge station

Converter leakage current detection

Standard

Applicable for IEC 62752 residual current requirements

Applicable for IEC 62955 residual current requirements for RDC-MD

Components designed full-fill RoHS/REACH

Overview

Accurate leakage current measurement Residual Current Monitoring Sensor.An important safety function of these devices is monitor of the leakage current of the entire system from Power modules against earth. A defective system can become dangerous for people or cause fires. Before it comes so far, Power modules must be disconnect from the grid. The leakage current contains DC and AC components. Therefore an AC/DC-sensitive monitoring unit is necessary.

ccurate leakage current measurement Residual Current Monitoring Sensor is widely applicable, especially in public charging stations for electric vehicles, electric motorcycles, electric bicycles, charging fees, and power safety management. It offers simple usage and easy installation.
