The DN20 LORA Valve-controlled Water Meter is a type of smart water meter with a nominal diameter of 20 millimeters. It utilizes Long Range (LORA) wireless communication technology and incorporates a valve for remote control of water flow.You can rest assured to buy DN20 LORA Valve-controlled Water Meter from our factory and we will offer you the best after-sale service and timely delivery.
DN20 LORA Valve-controlled Water Meter
- Advanced networking algorithm allows for long-distance communication in complex environments -
Utilizes relay method between neighboring nodes for efficient communication -
Series includes valve-controlled function for real-time valve control and prepayment - Suitable for installations in areas with concentrated water supply and transformation projects, meter replacement projects, rural drinking water projects, new residential buildings, and apartment metering projects -
DN20 size ensures compatibility with standard water connections -
Incorporates LORA technology for improved connectivity and communication - High-efficiency design for accurate and reliable water measurement -
Ideal for "Three Supplies and One Industry" transformation, meter replacement, rural drinking water, new residential buildings, and apartment metering projects.
Accuracy Class |
Class 2 |
Range Ratio |
R100 |
Nominal Diameter |
DN15~DN40 |
Maximum Pressure |
1.6MPa |
Working Environment |
Class B/O |
Temperature Class |
T30/T50/T90 |
Upstream Flow Sensitivity Level |
U10 |
Downstream Flow Sensitivity Level |
D5 |
Electromagnetic Compatibility Level |
E1 |
Communication Interface |
NB-IoT/Infrared |
Power Supply |
Built-in Lithium Battery (DC3.6V) |
Protection Level |
IP68 |
